INTRODUCTION

Embryonic development is characterized by the temporal and spatial regulation of cell proliferation, migration, differentiation, and tissue formation. Although these processes are genetically determined, several signaling mechanisms including Wnt have been recognized as essential in regulating cell lineage specification and organogenesis (13).

The Na/Kadenosine triphosphatase (ATPase) (NKA), discovered in crab nerve fibers by Skou (4), belongs to the P-type ATPase superfamily. It has an enzymatic function that couples adenosine 5-triphosphate (ATP) hydrolysis to the transmembrane movement of Na+ and K+ in a cell lineagedependent manner. For example, while the NKA is involved in the formation of action potentials in excitable cells, its polarized distribution is key to the functionality of the epithelium.

In addition to its canonical enzymatic function, we and others have shown that the NKA has an enzymatic activityindependent signaling function through its interactions with membrane cholesterol and proteins such as Src, epidermal growth factor (EGF) receptor, and caveolin-1 (58). We use the term signaling with liberty here, referring to the ability of NKA to work as a receptor, a scaffold, and a signal integrator by regulating the functions of its interacting proteins. This newly appreciated signaling function of the NKA has been implicated in several cellular processes (912). However, direct genetic evidence supporting a role for NKA signaling in animal physiology and disease progression is still lacking. This is due, in part, to the technical difficulties in studying its signaling separately from its ATPase-mediated pumping function because the latter is required for the survival of animal cells (13). Fundamentally, it is unknown whether the signaling function is an intrinsic property of the protein NKA, as its Na+- and K+-driven enzymatic activity has been recognized as. Therefore, we were prompted to address two important questions: (i) Were the signaling and Na+/K+ transport functions of the NKA coevolved? (ii) If so, does the signaling function of NKA represent a primordial yet common mechanism for the regulation of a fundamental process in animal biology?

Structurally, the NKA is composed of both and subunits. The subunit contains the binding sites for Na+/K+ as well as ouabain, which are distinct from that of other P-type ATPases (14). It also has an N-terminal caveolin binding motif (CBM) proximal to the first transmembrane helix (fig. S1A). To assess the functionality of this motif, we made F97A and F100A mutations that map to the rat 1 NKA sequence. This strategy has been used by others to study the function of CBM in proteins other than the NKA (15). We used a knockdown and rescue protocol to generate a stable cell line (LW-mCBM) that essentially expresses just the CBM mutant 1, which was confirmed using [3H]ouabain binding assays (fig. S1B). Western blot and confocal imaging analyses showed that the expression of mutant 1 NKA in LW-mCBM was comparable to that in the control cell line, named AAC-19 cells (fig. S1, B and C). The expression of CBM mutant 1 was sufficient to restore the expression of the 1 subunit of the NKA, allowing normal plasma membrane targeting of the CBM mutant NKA in LW-mCBM cells (fig. S1, C and D). The successful generation of a stable CBM mutant 1 cell line suggests that the CBM is not essential for the enzymatic activity of the NKA because the ion-transporting function is necessary for animal cell survival (13). In further support, we conducted kinetic studies of the CBM mutant NKA. As shown in Fig. 1A, the overall enzymatic activity per unit of 1 NKA expression was identical between the control AAC-19 and LW-mCBM cells. The Km values of Na+, K+, and ouabain were comparable between the CBM mutant NKA and control (Fig. 1, B to D) (16). Together, these data indicate that the N-terminal CBM is not directly involved in the regulation of the enzymatic properties of the NKA.

(A) Crude membrane preparations were made from AAC-19 and LW-mCBM cells and measured for ouabain-sensitive ATPase activity as described in Material and Methods. (B) Ouabain concentration curve. Crude membrane from LW-mCBM cells was prepared and measured for ATPase activity in the presence of different concentrations of ouabain. Data are shown as percentage of control, and each point represents three independent experiments. Curve fit analysis and IC50 (median inhibitory concentration) were calculated by GraphPad. (C and D) Measurements of Na+ and K+ Km. Assays were done as in (B). The combined data were collected from at least three repeats, and Km value (means SEM) was calculated using GraphPad.

On the basis of the above, we next turned our attention to determining the effects of the CBM mutation on signaling capabilities of the 1 NKA. Specifically, we first conducted immunoprecipitation experiments. As we reported previously in many types of cells (8), immunoprecipitation of caveolin-1 coprecipitated 1 in AAC-19 cells. In contrast, mutation of the CBM resulted in an over 80% decrease in coprecipitated 1 in LW-mCBM cells (Fig. 2A).

(A) Cell lysates from AAC-19 and LW-mCBM were immunoprecipitated (IP) with polyclonal anticaveolin-1 antibody. Immunoprecipitated complex was analyzed by Western blot for 1 and caveolin-1 (n = 4). **P < 0.01 compared to AAC-19. (B) Cell lysates from AAC-19 and LW-mCBM cells were subjected to sucrose gradient fractionation as described in Materials and Methods. A representative Western blot of three independent experiments was shown. **P < 0.01 in comparison to AAC-19. (C) AAC-19 and LW-mCBM cells were treated with different concentrations of ouabain for 10 min and analyzed by Western blot. A representative Western blot was shown (n = 4). *P < 0.05 versus 0 mM ouabain. (D) Cell growth curves of AAC-19 and LW-mCBM. *P < 0.05 versus AAC-19 cells. (E) BrdU assay of AAC-19 and LW-mCBM. The values are means SEM from at least three independent experiments. Photo credit: Xiaoliang Wang, Marshall Institute for Interdisciplinary Research at Marshall University.

To substantiate these observations, we next conducted a detergent-free and carbonate-based density gradient fractionation procedure and found that 1 NKA and its main signaling partners (Src and caveolin-1) were co-enriched in the low-density caveolar fractions, as previously reported in epithelial cells (8, 17). In sharp contrast, the expression of the CBM mutant 1 caused the redistribution of these proteins from low-density to high-density fractions (Fig. 2B). Quantitatively, when the ratios of fraction 4/5 of each protein versus total were calculated, we found that the low-density fraction 4/5 prepared from the control AAC-19 cells contained ~60, ~70, and 80% of caveolin-1, Src, and 1 NKA, respectively. However, in LW-mCBM cells, only ~20% of caveolin-1, Src, and 1 NKA were detected in fraction 4/5 (Fig. 2B).

To address the functional consequences of the dissociation of the 1 NKA from its signaling partners in LW-mCBM cells, we exposed these cells to ouabain, a specific agonist of the receptor NKA/Src complex. As shown in Fig. 2C, while ouabain stimulated phosphorylation of extracellular signalregulated kinase (ERK), a downstream effector of the NKA/Src signaling pathway in AAC-19 cells (5, 8), it failed to do so in LW-mCBM cells.

We have previously shown that 1 NKA signaling is key to the dynamic regulation of cell growth (16, 18). As shown in Fig. 2D, LW-mCBM cells grew much slower than AAC-19 cells. 5-Bromo-2-deoxyuridine (BrdU) incorporation assays further verified that the expression of CBM mutant 1 resulted in an inhibition of cellular proliferation (Fig. 2E). In short, the above in vitro experiments indicate that the gain of CBM enables the NKA to perform the enzymatic activityindependent signaling functions.

With the preceding in vitro data suggesting that the CBM is critically important to the signaling function of the NKA, we next set forth to test the physiological significance of this finding. Thus, we generated a knock-in mouse line expressing the aforementioned CBM mutant 1. The CBM mutant (mCBM) mouse was generated using the Cre/LoxP gene targeting strategy (19), as depicted in fig. S2A. The chimeric offspring were crossed to C57BL6 females to yield mCBM heterozygous mice, and the desired F97A and F100A substitutions were verified (fig. S2B). mCBM heterozygous mice were born fertile and survived to adulthood. Our attempts to generate mCBM homozygous mice yielded no viable homozygous pups (Fig. 3A) in nearly 400 young mice genotyped by polymerase chain reaction (PCR). These results document for the first time that the CBM in the 1 subunit of the NKA represents a fundamental signaling mechanism essential for mouse embryonic development and survival.

(A) Early embryonic lethality of mCBM homozygous embryos. (B) Morphological comparison and body size of wild-type (WT) (top), heterozygous (middle), and homozygous (bottom) mCBM embryos at E9.5. Black bars, 0.3 mm. The arrows show the abnormal head morphology. Body size was measured from at least 12 embryos in different genotypes by ImageJ. Data are presented as means SEM. ***P < 0.01 versus the average of WT. (C) Sagittal sections of WT and homozygous (Homo) and heterozygous (Het) embryos at E9.5 with hematoxylin and eosin (H&E) staining. Homozygous embryos that had defective brain development indicated by open arrows. (D) Brain cross section of WT, homozygous, and heterozygous embryos at E9.5 with H&E staining. Homozygous embryos that had unclosed neural tube in forebrain, midbrain, and hindbrain were indicated by arrows; WT and heterozygous E9.5 embryos with closed neural tube were indicated by arrowhead. (E) Morphological comparison of WT and Na/K-ATPase 1 (+/) embryos at E9.5. White bars, 0.3 mm (n = 5 to 7). Photo credit: Xiaoliang Wang, Marshall Institute for Interdisciplinary Research at Marshall University.

There is evidence that endogenous ouabain is important in animal physiology because of its role in stimulating the signaling function of the NKA (10, 19, 20). Because the loss of the CBM abolishes ouabain-induced signal transduction in vitro, we tested whether administration of pNaKtide, a specific inhibitor of the receptor NKA/Src complex (21), would cause the same embryonic lethality as we observed in mCBM mice. As depicted in fig. S3, we observed no change in fetal survival after administration of pNaKtide to female mice before mating and continued until the end of pregnancy. It is important to mention that pNaKtide has been proven to be specific and effective in blocking the NKA/Src receptor signaling in vivo (2226), and our control experiments showed that pNaKtide could cross the placental barrier. Moreover, this lack of pNaKtide effect on mouse embryogenesis appears to be consistent with a previous report demonstrating that neutralization of endogenous ouabain by injection of an anti-ouabain antibody did affect the kidney development of neonatal mice but did not affect their overall survival (20). On the basis of these, we concluded that the NKA/Src receptor function in the CBM mutant embryo was not the direct cause of lethality and set out to identify a hitherto unrecognized NKA CBM-dependent yet NKA-Srcindependent underlying mechanism.

Embryo implantation within mice occurs around embryonic day 4.5 (E4.5) (27), followed by gastrulation around E5.5 to E7.5 (28), when the simple embryo develops into an organized and patterned structure with three germ layers (29). Subsequently, organogenesis takes place at E8.0 and onward; the patterned embryo starts to develop its organ systems including the brain, heart, limbs, and spinal cord.

To further analyze and explore the molecular mechanisms of the CBM mutation in the embryonic development of mice, we harvested the fertilized eggs at E1.5, and cultured them in vitro. It has previously been demonstrated that 1 knockout results in the failure of blastocyst formation (13). In contrast, we found that eggs from mCBM heterozygous parents developed into morphologically normal blastocysts. These findings indicate that loss of the CBM does not affect the molecular mechanisms necessary for blastocyst formation. Thus, a loss of functional 1 CBM and complete knockout of 1 NKA both result in embryonic lethality but differ by their specific mechanisms. Knockout of 1 NKA inevitably causes the loss of NKA enzymatic function, which is incompatible with life (13), and results in the failure of blastocyst formation in mice. In contrast, our in vitro data indicate that a loss of the CBM does not cause any notable alteration in NKA enzymatic activity, which is supported by the observation that mCBM mice are still capable of producing morphologically normal blastocysts. Consequently, CBM role in development appears to be critical at a developmental stage beyond blastocyst stage, and we further set out to identify this stage.

To this end, we collected and genotyped embryos or yolk sacs from mCBM heterozygous mice at different days of gestation. We first dissected 31 embryos at E12.5 from three different mice (Fig. 3A). Reabsorption and empty deciduae were observed in six implantation sites with only the mothers genotype detectable. At E9.5, we were able to dissect a total of 303 embryos. Sixty-four of them were mCBM homozygous (21%), 71 were wild-type (23%), and 168 were mCBM heterozygous (55%) (Fig. 3A).

To further analyze the embryonic developmental defects, we examined mCBM embryos at E7.5, E8.5, and E9.5. The embryos looked similar between wild-type and mCBM homozygous mice at E7.5 and E8.5 under dissection microscopy. However, we found several severe morphological defects in homozygous embryos at E9.5 (Fig. 3, C and D). First, the overall size of embryos was considerably reduced in mCBM homozygous embryos (about 35% the size of the wild-type embryos). In addition, the observed effect of the CBM mutant on embryonic size was gene dose dependent, as the mCBM heterozygous embryos were significantly smaller than those of wild-type embryos but much bigger than the homozygous embryos. Second, most homozygous embryos did not turn, a process normally initiated at E8.5, suggesting that the loss of a functional CBM was responsible for a developmental arrest at an early stage of organogenesis. Last, the most severe morphological defects were observed in the heads of the mCBM homozygous embryos. In addition to the reduced size (about 25% of the size of wild-type embryos), we observed that mCBM homozygous embryos failed to close their cephalic neural folds (anterior neuropore) as indicated by the arrow in Fig. 3B. This phenotype more closely resembled wild-type embryos at E8.0 to E8.5, suggesting again that the loss of CBM arrested organogenesis in its early stages. On the other hand, all heterozygous embryos, although smaller than wild-type embryos, showed normal head morphology (Fig. 3B).

To follow up on the above observations, we collected and made histological sections of wild-type, heterozygous, and homozygous embryos at E9.5 (Fig. 3, C and D). Normally, formation and closure of the anterior neuropore occurs at E9.5 (Fig. 3D). In sharp contrast, mCBM homozygous embryos developed defects in neural closure. Specifically, failure of neural tube closure at the level of forebrain, midbrain, and hindbrain was prominent in homozygous embryos (Fig. 3D).

To further explore the molecular mechanism by which the loss of the CBM led to defects in organogenesis, we next conducted RNA sequencing analyses (RNAseq) in wild-type and mCBM homozygous embryos. More than 17,000 genes were read out in either mCBM homozygous or wild-type samples. Data analyses indicated that 214 and 208 genes from mCBM homozygous embryos were significantly down- and up-regulated, respectively (fig. S4). Among them, the expression of a cluster of transcriptional factors important for neurogenesis was significantly reduced. As depicted in Fig. 4A, the expression of neurogenin 1 and 2 (Ngn1/2), two basic helix-loop-helix (bHLH) transcriptional factors (30), was significantly down-regulated in homozygous embryos. Ngn1/2 are considered to be determination factors for neurogenesis, while members of the NeuroD family of bHLH work downstream to promote neuronal differentiation (31). We found that the expression of NeuroD1/4 was further reduced in mCBM homozygous embryos. As expected from these findings, the marker of neural stem cells nestin (Nes) and other genes related to neurogenesis including huntington-associated protein 1 (Hap1), nuclear receptor subfamily 2 group E members 1 (Nr2e1), and adhesion G protein (heterotrimeric guanine nucleotidebinding protein)coupled receptor (Adgrb1) were all down-regulated in mCBM homozygous embryos (Fig. 4A). To verify these data, we performed reverse transcription quantitative PCR (RT-qPCR) analyses of both wild-type and mCBM homozygous embryos collected at E9.5. As depicted in Fig. 4 (B to D), the aforementioned transcriptional factors were all down-regulated in a cascade fashion. While a modest reduction was found with Ngn1/2, the expression of NeuroD1/4 was almost completely inhibited. To test whether the effects of the CBM mutation on the expression levels of these transcriptional factors were gene dose dependent, we also examined mRNA levels of Ngn1/2 and NeuroD1/4 in mCBM heterozygous embryos. As depicted in Fig. 4 (B and C), the expression of these genes followed the pattern found in homozygous embryos. The expression level in heterozygous embryos was significantly reduced compared to wild-type embryos but was much higher than that of mCBM homozygous embryos. These gene dosingdependent cascade effects suggest that the 1 NKA is an important upstream regulator but not a determinant of neurogenesis like Ngn1/2 (32) or a key receptor mechanism like Wnt is.

(A) RNAseq results of several neurogenesis and neural stem cell markers. Log2 ratio = 1 means twofold of change. *P < 0.05 compared to WT. (B and C) RT-qPCR analysis of selected gene expression in WT, heterozygous, and homozygous mCBM embryos at E9.5. (D) RT-qPCR analysis of neural stem cell marker gene expression in WT and homozygous mCBM E9.5 embryos. (E) RT-qPCR analysis of neurogenesis marker genes in WT and NKA 1+/ mouse E9.5 embryos. Quantitative data are presented as means SEM from at least six independent experiments. *P < 0.05, **P < 0.01 versus WT control.

As a control, we also assessed the expression of different isoforms of NKA and caveolin-1. As depicted in fig. S5, no changes were detected in the expression of the 1 isoform of the NKA. This is expected, as the mutations were only expressed on exon 4. Previous reports have demonstrated that, in addition to the 1 isoform, neurons also express the 3 isoform, while muscle and glial cells express the 2 isoform of the NKA (9). No difference was observed in the expression of 3, while the expression of 2 was too low to be measured. We were also unable to detect any change in the expression of caveolin-1.

The total amount of protein recognized by the anti-NKA 1 antibody is unchanged in mCBM heterozygous mouse tissues compared to that of the wild type, albeit with changes in distribution in caveolar versus noncaveolar fractions. This indicates that the CBM mutant protein is fully expressed, as observed in cells (fig. S1), and further demonstrates that a reduction of enzymatic activity is not responsible for the observed phenotype in mCBM homozygous embryos. However, because the expression of wild-type 1 in mCBM heterozygous animals is most likely reduced, the phenotypic changes we observed in these mice could be due to the reduction of wild-type 1 expression rather than the expression of CBM mutant 1. To address this important issue, we collected embryos from 1 NKA heterozygous (1+/) mice and their littermate controls (33). In contrast to mCBM heterozygotes, reduction of 1 expression alone did not change the size of embryos (Fig. 3D), head morphology, or the expression of neuronal transcriptional factors (Fig. 4E). Because NKA 1 haploinsufficiency did not phenocopy mCBM heterozygosity, it was concluded that the mCBM allele was responsible for the observed changes.

The CBM in NKA has a consensus sequence of FCxxxFGGF (fig. S6). To assess the generality of CBM-mediated regulation, we first turned to the conserveness of the CBM in animal NKA. A database search reveals that, like Wnt, the mature form of NKA (i.e., containing CBM, Na+/K+ binding sites, and subunit) is absent in unicellular organisms but present in all multicellular organisms within animal kingdom (fig. S6). Further analysis of published data confirms the coevolutionary nature of the CBM and the binding sites for Na+ and K+ in the NKA. The first indication is from the analysis of single-cell organisms. No mature form of NKA is found in these organisms (fig. S6A). However, Salpingoeca rosetta, a marine eukaryote belonging to the Choanoflagellates class, undergoes a very primitive level of cell differentiation and specialization in their life cycle and expresses a putative NKA with several conserved motifs involved in the binding of Na+/K+. On the other hand, it contains no CBM (fig. S6) and there is also no evidence that it expresses a subunit.

Second, as depicted in figs. S6 and S7, Caenorhabditis elegans, an example of a metazoan organism, expresses a mature form of NKA (eat-6) that contains binding sites for Na+ and K+ as well as the N-terminal CBM. It also expresses a couple of putative NKA such as catp-2 (34). However, they contain neither the CBM nor Na+ and K+ binding sites.

Third, although the X amino acids in the NKA CBM in invertebrates vary, only conserved substitutions occurred in this motif. This is in sharp contrast to many other membrane receptors/transducers such as Patched and G that also contain a consensus CBM (figs. S6 and S7). Within vertebrates, the CBM sequence FCRQLFGGF in NKA remains completely conserved across all species. Moreover, this sequence remains conserved in all isoforms of the subunit except for the 4 isoform, which is exclusively expressed in sperm. The 4 isoform in some species still adapts the CBM sequence found in invertebrates (fig. S6). Moreover, of a total of nine subunits found in zebrafish (35), five appear to be 1 homologs that, like the 4 isoform, contain both vertebrate and invertebrate CBM sequences.

Last, turning to the evolutionary aspect of the receptor NKA/Src complex, we found that the Src-binding NaKtide and Y260 sequences, in sharp contrast to the CBM, are only conserved in mammalian ATP1A1 (fig. S7). Therefore, the NKA/Src receptor may have evolved after the acquisition of the CBM, and hence is not a part of the fundamental regulation of animal organogenesis (fig. S3).

In short, the N-terminal CBM, like the binding sites for Na+ and K+, is conserved in all subunits of NKA in animals, even after taking into consideration gene duplications and the generation of different isoforms or homologs. Thus, we postulate that this CBM must be evolutionally conserved to enable the NKA, in parallel with its enzymatic function, to serve an important role in the origination of multicellular organisms within the animal kingdom.

Organogenesis represents a unique feature of multicellular organisms. In considering the preceding findings, we reasoned that the loss of NKA CBM would also affect embryonic development in invertebrates such as C. elegans. To test our hypothesis, we used CRISPR-Cas9 to knock in the equivalent CBM double mutations of F75A and F78A in C. elegans NKA gene eat-6 (named as syb575) (fig. S8). Similar to the impact of the expression of CBM mutant 1 NKA in mice, no homozygous worms were produced, whereas the heterozygous worms hatched normally. Moreover, by using the gene balancer nT1, we confirmed that the F75A and F78A double mutations induced embryonic lethality in syb575 homozygotes secondary to L1 arrest (Fig. 5A). Furthermore, the observed larval arrest due to the loss of the eat-6 CBM was rescued by a transgene expressing a wild-type eat-6 complementary DNA (cDNA) through an extrachromosomal array (Fig. 5B). The lethality phenotype in syb575 mutants was different from those of the eat-6 mutants defective in enzymatic (transport) activity, because while the eat-6 mutants had growth defects, they were able to grow past the L1 stage (36). An exception to this was a cold-sensitive eat-6 (ad792) mutant with severely reduced transport activity, which exhibited L1 arrest at lower temperatures similarly to the syb575 mutant worms (36). Overall, those data suggest that both CBM-mediated signaling and ion transport activity by the NKA are essential to full-scale organogenesis in C. elegans.

(A) Heterozygous CBM mutant (mCBM) worms syb575/nT1 have GFP signals in pharynx (pointed with the arrowhead), while mCBM homozygous worms are GFP negative and arrested at larval stage (pointed with an arrow). (B) Rescue with a WT eat-6 gene showing a mCBM homozygous worm with a transgenic marker sur-5::GFP. Arrow points the somatic GFP signals. (C) Mutation of CBM1 NKA (F97A; F100A) results in reduced colony formation in human iPSC (mCBM iPSC). (D) RT-qPCR analysis of stem cell markers and primary germ layer markers in WT and mCBM iPSC. *P < 0.05 compared to WT. n = 7. Photo credit: Liquan Cai, Marshall Institute for Interdisciplinary Research at Marshall University.

In short, our data indicate that loss of the NKA CBM results in defective organogenesis in both mice and C. elegans. This, together with our finding that the NKA CBM is conserved in all NKA regardless of isoform or homolog, indicates that the NKA was originally evolved as a dual functional protein in multicellular organisms, and that it represents a primordial and common mechanism for regulating stem cell differentiation and early stage of organogenesis in animals.

Turning now to even more general features of the CBM in organogenesis, we searched for the plant plasma membrane H-ATPase that functions equivalently to the animal NKA. Like the NKA, the plant plasma membrane H-ATPase also contains a sequence motif at the first transmembrane segment that is in accordance with the consensus CBM. This motif is completely conserved from blue algae to land plants but does not exist within yeast and bacteria (fig. S6).

To assess the human relevance of our findings, we used CRISPR-Cas9 gene editing to generate the same mutations in human induced pluripotent stem cells (iPSCs) (fig. S9). As depicted in Fig. 5C, the expression of mutant CBM 1 reduced the colony formation ability of human iPSCs. Concomitantly, this was accompanied by a significant reduction in the expression of stemness markers (both Nanog and Oct4), and transcriptional factors controlling germ layer differentiation (gene MIXL and T for mesoderm, OTX2 and SOX1 for ectoderm, and GATA4 and SOX17 for endoderm) (Fig. 5D). These findings confirm an essential role of the NKA CBM in the regulation of stem cell differentiation and suggest the potential utility of targeting the NKA for improving tissue regeneration.

The canonical Wnt pathway is made of multiple components localized in the plasma membrane and cytosol (2, 3). Functionally, this pathway is critically important in animal organogenesis (2, 37). For example, it plays an essential role in the establishment of neurogenic niches and regulates the differentiation of neural stem cells into neuroblasts during organogenesis by regulating the expression of transcriptional factors Ngn and NeuroD (37, 38). Thus, we were prompted by the observed neural defects in mice to test whether the expression of the CBM mutant 1 NKA affects Wnt/-catenin signaling.

In the first set of studies, we examined the cellular distribution of -catenin in LW-mCBM cells. As depicted in Fig. 6A, confocal imaging analysis showed that -catenin was distributed away from the plasma membrane in a vesicle-like form in LW-mCBM cells. To verify this finding, we fractionated the cell lysates as performed in Fig. 3B and observed that -catenin, like Src and caveolin-1, moved from the low-density fractions to high-density fractions when compared to control cells (Fig. 6B). Control experiments showed no changes in the expression of E-cadherin, glycogen synthase kinase3 (GSK-3), LRP5/6 (Low-density lipoprotein receptor-related protein 5 and 6), and -catenin in LW-mCBM cells (Fig. 6C).

(A) -Catenin staining of AAC-19 and LW-mCBM at basal level (n = 5). Blue arrow indicated -catenin signal in the cytoplasm of cells. (B) Sucrose gradient fractionation of -catenin in AAC-19 and LW-mCBM cells (n = 3). **P < 0.01. (C) Western blot analysis of Wnt/-catenin signaling proteins in AAC-19, LX-2, and LW-mCBM cells from at least six independent experiments. Two samples from each cell lines are presented. (D) Wnt3a induced TOPFlash luciferase report assay in AAC-19 and LW-mCBM (n = 8). ***P < 0.01. (E) Wnt3a induced expression of Wnt/-catenin targeting genes (n = 8). **P < 0.01. (F) Wnt3a induced TOPFlash luciferase report assay in AAC-19, LX-2, and LW-mCBM cells (n = 4). ***P < 0.01.

To test whether these changes in -catenin distribution alter the function of canonical Wnt signaling, we conducted a TOPFlash luciferase activity assay (39). Cells were transiently transfected with the reporter plasmid, exposed to Wnt3a conditional medium, and then subjected to TOPFlash luciferase assays. As shown in Fig. 6D, while Wnt3a induced a greater than 35-fold increase in luciferase activity in AAC-19 cells, it only produced a fourfold increase in LW-mCBM cells, which equates to an approximate 90% reduction in the dynamics of Wnt activation. To further test the impact of the CBM mutation on Wnt signaling, we examined the effects of Wnt3a on the expression of Wnt target genes. Cells were exposed to Wnt3a for 6 hours and subjected to RT-qPCR analysis. As depicted in Fig. 6E, while Wnt3a increased the expression of c-Myc, Lef, and NKD1 expression in AAC-19 cells, it failed to do so in LW-mCBM cells.

On the basis of the above observations, we reasoned that the NKA CBM might play an essential role in the dynamic regulation of Wnt signaling. We therefore analyzed Wnt signaling in our LX-2 cell line. This cell line was made by the same strategy used for the generation of LW-mCBM cells, and it expresses essentially just the 2 isoform (40). We have observed that 2 NKA, like CBM mutant 1, maintains cellular pumping capacity but is unable to signal via Src like a wild-type 1 NKA (40). However, unlike CBM mutant 1, 2 does contain the same CBM at the N terminus (fig. S6). As depicted in Fig. 6F, expression of the 2 isoform produced a rescue of Wnt signaling dynamics when compared to that in LW-mCBM cells, which reinforces the idea that the NKA CBM is key to the dynamics of Wnt signaling. Like in LW-mCBM cells, no change in -catenin expression was noted in LX-2 cells. However, compared to LW-mCBM cells, caveolin-1 expression was decreased in LX-2 cells, while ERK activity was increased (Fig. 6C). Together, these findings suggest that the conserved NKA CBM is essential for regulating Wnt signaling, which is independent of the pumping or CTS (ardiotonic steroid)activated Src-dependent signaling transduction.

To see whether there is evidence of Wnt signaling defects in mCBM homozygous embryos, we examined the RNAseq data using a tool kit of pathway analysis. As depicted in fig. S10, Wnt signaling appears to be defective at the transcriptional level. First, the expression of one of the Wnt receptors [Frizzled homolog 5 (Fzd5)] and one of the Wnt ligands (Wnt7b) was down-regulated (fig. S10A). Second, the Wnt/-catenin signaling inhibitor, secreted frizzled-related protein 5 (Sfrp5), was up-regulated in mCBM homozygous embryos. Third, the -catenin destruction complex component adenomatosis polyposis coli (APC) was down-regulated in mCBM homozygous embryos. All these defects in Wnt signaling were confirmed by RT-qPCR analysis of both wild-type and mCBM homozygous embryos at E9.5 (fig. S10B). In addition, APC down-regulation was also observed at the protein level in mCBM iPSCs (fig. S10C). Last, the defect in Wnt signaling was further substantiated by the altered expression of Wnt downstream target genes. As shown in fig. S10B, the expression of Lef and NKD1 was significantly reduced in mCBM homozygous embryos. The expression of c-Myc was too low to be detected.

Together, these data provide strong support to the notion that the CBM is a key to the regulation of Wnt by the NKA. We hypothesize that this critical function of the NKA CBM may explain why the CBM is conserved in all four subunit isoforms of the NKA. It is important to mention that the specific molecular defects in Wnt signaling that we have identified were tested in epithelial cells, a model we have previously used to characterize 1-specific signaling functions (16, 41). In view of the cell/tissue specificity of both NKA expression and subunit assemble (42) and Wnt signaling (13, 37), it is likely that this mechanism does not fully explain the Wnt signalingrelated defects in embryogenesis.

The enzymatic function of NKA coordinates the transmembrane movement of Na+/K+, which is essential for the survival of individual animal cells. At the tissue/organ level, the ATP-powered transport of Na+/K+ by the NKA is required for neuronal firing, muscle contraction, and the formation and functionality of epithelia and endothelia. The NKA was found to be essential for forming septate junction in Drosophila melanogaster (43, 44) via a regulatory mechanism independent of its ion-pumping activity. Here, we reveal an additional fundamentally important role of NKA in the regulation of signal transduction through a separate functional domain (CBM) unrelated to its enzymatic activity.

Our findings raise the question of why NKA acquired the CBM in addition to its binding sites for Na+ and K+. One possible explanation for this is that the additional functionality in NKA (fulfilled by the CBM) evolved for the purpose of regulating stem cell differentiation and organogenesis in multicellular organisms. Two observations support this hypothesis. First, both Wnt and NKA are present in the first multicellular organisms within the animal kingdom and are evolutionally conserved ever since. Thus, it is likely that the NKA and Wnt work in concert to enable stem cell differentiation and organogenesis in animals. Second, while Wnt is key to the cellular programs of stemness and cell lineage specification (2), it does not directly participate in cell lineagespecific activities of newly differentiated cells. Instead, this particular function might be fulfilled by the NKA. Conceivably, the NKA could have been evolved, as exemplified by the mitochondrial cytochrome c in ATP generation, to bring together two seemingly unrelated processes (i.e., Wnt signaling regulation via the CBM and ion transport through Na+ and K+ binding) into one signaling circuitry, which is critical to the dynamic regulation of transcriptional factors that are required for organogenesis in a temporally and spatially organized manner. Needless to say, this hypothesis remains to be tested. In addition, other important signaling pathways such as Notch and Sonic Hedgehog may also be regulated by NKA.

It is also of interest to note the evolutionary conserveness of the CBM in the plant plasma membrane H-ATPase. Like its counterpart within the animal kingdom, the plasma membrane H-ATPase is essential for plant organogenesis (45). Unlike the NKA, the plasma membrane H-ATPase exists in single-celled organisms such as yeast, and their ion-pumping function is regulated by similar mechanisms (46). However, yeast, with no use for cellular machinery needed for organogenesis, does not contain the H-ATPase with conserved CBM. Moreover, we also observed that no CBM exists in the plasma membrane Ca-ATPase (fig. S6), both of which belong to the same type II P-type ATPase family as the NKA. While the Ca-ATPase is a more ancient protein than the NKA, as its expression can be found in unicellular organisms, the H/K-ATPase appeared later than the NKA, at some point during the development of vertebrates. Thus, we suggest that the NKA may have evolved from a P-ATPase of unicellular organisms via the gain of both the CBM and Na+/K+ binding sites. In contrast, the H/K-ATPase may have evolved from the NKA, losing not only the Na+ binding site but also the CBM.

We have shown a direct interaction between the NKA and caveolin-1 (8, 17), which has been independently confirmed (47). The loss of the CBM significantly reduced the interaction between NKA and caveolin-1 as revealed by multiple assays. In addition to caveolin-1, we and others have reported several signal transductionrelated interactions (48). Of these, the potential interaction between 1 NKA and Src has attracted the most attention, especially in the past 10 years (7). While most studies indicated an important role of Src in CTS-activated signal transduction via 1 NKA, several publications have questioned whether 1 NKA interacts with Src directly to regulate Src functionality (49, 50). While this important difference remains to be experimentally addressed, we would like to point out the following facts. First, while we recognize the merit of using purified protein preparation to study protein interaction, it is important to recognize the limitation of using purified Src from bacterial expression system because they are heterogeneously phosphorylated. Second, we have reported multiple lines of evidence that support a direct interaction between 1 NKA and Src, including the identification of isoform-specific Src interaction, the mapping of potential Src-interacting sites in the 1 isoform, and the development of pNaKtide as Src inhibitor and receptor antagonist. These findings have substantially increased our understanding of 1 NKA/Src interaction in cell biology and animal physiology. It is important to mention that several groups not associated with us have successfully used pNaKtide to block ouabain and NKA signaling in vitro and in vivo (2326, 51). While our group and others continue to characterize the molecular basis and biological function of the NKA/Src receptor complex, we propound that the question of NKA/caveolin-1 interaction is a more pressing one in the context of this study. The role of CBM in caveolin-protein interaction and caveolae-related signaling is still debated (41, 52, 53).

Last, we conclude from these interesting findings that the NKA is not just an ion pump or a CBM-directed regulator but a critical multifunctional protein. This whole functionality underlies a hitherto unrecognized common mechanism essential for stem cell differentiation and organogenesis in multicellular organisms within the animal kingdom. Moreover, many recent studies also support the concept that the 1 NKA has acquired more functional motifs (e.g., Src-binding sites for the formation of NKA/Src receptor complex) during evolution. In addition, we have demonstrated that either knockdown of 1 NKA or the expression of an N-terminal fragment containing the CBM of the 1 subunit was sufficient to attenuate purinergic calcium signaling in renal epithelial cells (54). The 1 NKA is also found to be essential for CD36 and CD40 signaling in macrophages and renal epithelial cells (55, 56). Aside from the profound biological and fundamental implications, the previously unidentified NKA-mediated regulation of Wnt signaling through its N-terminal CBM may have substantial implications in our understanding of disease progression. The rapidly increasing appreciation of Wnt signaling in the pathogenesis of cancer and cardiovascular diseases (2, 3, 38) underlies the potential utility of NKA as a multidrug target (12, 22, 57, 58).

Acknowledgments: Funding: This work was supported by grants from: National Institutes of Health (NIH) Research Enhancement Award (R15) (R15 HL 145666); American Heart Association (AHA) Scientist Development Grant (#17SDG33661117); Brickstreet Foundation and the Huntington Foundation, which provide discretionary funds to the Joan C. Edwards School of Medicine. (These funds are both in the form of endowments that are held by Marshall University). Author contributions: Conceptualization: Z.X., X.W., J.X.X., L.C., G.-Z.Z., S.V.P., and J.I.S.; methodology: X.W., L.C., I.L., D.W., and G.-Z.Z.; investigation: X.W., L.C., X.C., J.W., Y.C., and J.Z.; writing (original draft): X.W., J.X.X., and Z.X.; writing (review and editing): Z.X., J.X.X., L.C., J.I.S., S.V.P., D.W., G.-Z.Z., and X.W.; funding acquisition: Z.X.; visualization: X.W. and Z.X. Competing interests: The authors declare that they have no competing interests. Data and materials availability: All data needed to evaluate the conclusions in the paper are present in the paper and/or the Supplementary Materials. Additional data related to this paper may be requested from the authors.
